| BRAND | Berthold |
| Product | 53214-014 |
| Internal code | IMP513408 |
| Weight | 1 |
| Technical specification | UniProbe LB 490 Super-Sens Level Evaluation Unit super sensitive probe for radiometric measurements Organic scintillator 150/150 Collimator for irradiation: radial, 66° with lead shielding for reduction of background radiation Power supply 95 - 250 V, 50 - 60 Hz Menu controlled calibration via HART-communicator Automatic decay compensation Error indication Ambient temp: -40 to +55 - 1 analog output: 0/4 - 20 mA, isolated, - 1 digital-Input for hold-signal Relays: Max. 250VAC or 30VDC at max. 5A noninductive - 3 relays, alternative signals: hold, max / min alarm, detector temp., rad. interference - 1 failure relay 4 conduits radial 3/4" NPT Flame proof protection: ATEX: II 2(1)GD Ex d [ia] IIC T6 IP66 T 80°C current output, intrinsically safe, sink mode with 20m cable, blue, pre-assembled with cable gland, nickel-plated protection: Nema 4X / IP 66 housing: stainless steel with water cooling Customs tariff number: 90222900 |
