| BRAND | Honsberg |
| Product | 946345 MR1K-015GM002-125 |
| Description | flow monitor |
| Internal code | IMP595602 |
| Weight | 1.3 |
| Custom code | 85365080 |
| Technical specification | MR1K flow monitor Display options: No mechanical display Nominal diameter: DN 15 - G ½ Connection type: internal thread Connection material: nickel-plated brass Pressure resistance: PN 200 Internal parts: stainless steel Seals: FKM Media temperature: -20... +120 °C Ambient temperature: -20... +70 °C H2O switching range: 0.4... 2 l/min H2O Switch head: plastic, flat Adjustment: oblong hole El. Connection: DIN 43650-A/ISO 4400 plug El. Contact: reed switch Contact rating: 120 V AC 0.18 A 5 VA/175 V DC 0.25 A 5 W Connection diagram: Changer, connection diagram no. 0.213 Protection class: IP65 Flow direction: Horizontal from left with gearhead limiter, Viton damping with VA piston |
