| BRAND | Ephy Mess |
| Product | 986090616000002 |
| Internal code | IMP4749823 |
| Weight | 0.43 |
| Custom code | 90259000 |
| Technical specification | PR-SPA-EX-LTH IBExU 14 ATEX 1291 X, II 2G Exia IIC T6... T3 Gb Please_Note_Manual_Point_10 IECEx IBE 14.0048X, Exia IIC T6... T3 Gb EAC RU C-DE.BH02.в.00338/20, 1 Exia IIC T6... T3 Gb Coblh. _п._12_RPM № 81831-21 screw-in resistance thermometer, LT-38, 2Pt100, 3-wire circuit Class B ±0.3°C at 0°C in accordance with DIN EN 60751 EM38 connection head, brass diam.: ø8x340mm, cover: no, Molded: yes Cable outlet: M20x1.5 VSB: mobile, stainless steel, NPT 1/2"/SW 27 Cutting ring: stainless steel, ø8.1mm Supply line: shielded hose cable 1x [8xAWG 26/7-Cu-silver-plated/PTFE/glass fibre/PTFE peeling foil/VA, KL=3000mm, diameter: 4.20mm] - (RD/RD/WH/BK/BK/YE), Measuring range: -60°C... +180°C Ambient temperature: -60°C... +100°C Dielectric strength: 2.5 kV AC. 50 Hz/1min. Dielectric strength: element against element: 0.5 kV AC. 50 Hz/1min. Shield not placed on sensor housing incl. meter Certificate and passport Attention, when connecting, note: Not the shields of the measurement line Hang up. Country of origin: Germany AL: N/ ECCN: N/ HS/Custom Tariff: 90259000 Net weight: 426.35 g/piece The user manual is delivered in German or English. ATTENTION: Please check with your ATEX representative that the above articles meet your structural requirements if the articles only have an ATEX partial certificate (U) and not an ATEX full certificate (X). EPHYMESS is unable to perform this check. * 998100220000001 Delivery from stock, subject to intermediate sale TR-Ex, EAEC RU C-EN.BH02.в.00338/20 (for LTH, NWT, WKF) Ignition protection type for LTH: 1Ex and IIC T6... T3 Gb Ex tb IIIC T80°C/T95°C/T130°C/ T180°C Db 1Ex ia IIC T6... T3 Gb Ex ia IIIC T80°C/T95°C/T130°C/T180°C Db Ignition protection type for NWT and WKF: Ex e II Gb U, Ex tb IIIC Db U Ex ia IIC Gb U, Ex ia IIIC Db U AL: N/ECCN: N The user manual is delivered in German or English. ATTENTION: Please check with your ATEX representative that the above articles meet your structural requirements if the articles only have an ATEX partial certificate (U) and not an ATEX full certificate (X). EPHYMESS is unable to perform this check. * 998140621000001 Delivery from stock, subject to intermediate sale Metrological_certificate_ PR-Spa-ex/na-lth, PR-Spa-ex/na-WKF, PR-Spa-ex/na-nwt, No.: 81831-21, valid for Russia The official validity is determined by Database entry displayed AL: N/ECCN: N 998181212000001 |
Where can I buy 986090616000002 by Ephy Mess in Germany?
You can purchase 986090616000002 by Ephy Mess from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the 986090616000002?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Ephy Mess in Germany?
While we are not the official distributor or seller of Ephy Mess in Germany, we source our products from reliable channels and offer you original Ephy Mess equipment at competitive prices.
How can I access 986090616000002 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 986090616000002 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 986090616000002?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
