Prices 994240204000002 Ephy Mess Germany

BRAND	Ephy Mess
Product	994240204000002
Description	Pinion bearing resistance thermometer
Internal code	IMP5033321
Weight	0.26
Custom code	90259000
Technical specification	994240204000002 temperature sensor, Talgo 2Pt100, 2 wire circuit Class B ±0.3°C at 0°C in accordance with DIN EN 60751 connection head, brass, height=16mm Size: Ø5xEL=37mm, stainless steel, SJTG06RT12-98SN023M129 connector, Supply line: shielded hose cable 1x [4xAWG 24/7-Cu-silver-plated/STP/Cu-tin-plated/STP, Kl=2220mm, diameter: 4.20 mm] BK (WH/RD/RD), corrugated plastic pipe hose AØ=13mm, Measurement range: -40°C... +200°C Ambient temperature: -40°C... +100°C Temperature - head: -40°C... +100°C Insulation resistance: ≥ 200 MΩ/1000 VDC Shield not placed on the sensor housing Shield placed on the plug housing Dimension B=2220mm, Sensor head with detachable screws M6x22 Contact assignment A-B and C-D Short-term operating temperature: 250 °C Country of origin: Germany AL: N/ECCN: N/HS/Custom Tariff: 90259000 Net weight: 260 g/piece

Ephy Mess - 994240204000002 referenced Pinion bearing resistance thermometer product produced by high technology.
994240204000002 became irreplaceable of foundations. 994240204000002 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. 994240204000002 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy 994240204000002 by Ephy Mess in Germany?

You can purchase 994240204000002 by Ephy Mess from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.

What is the price of the 994240204000002?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Ephy Mess in Germany?

While we are not the official distributor or seller of Ephy Mess in Germany, we source our products from reliable channels and offer you original Ephy Mess equipment at competitive prices.

How can I access 994240204000002 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 994240204000002 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 994240204000002?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
