Prices 995150302000001 Ephy Mess Germany

BRAND	Ephy Mess
Product	995150302000001
Description	Harness, AVE transmission/Gearbox
Internal code	IMP4226171
Weight	0.5098
Custom code	90259000
Technical specification	2Pt100, 2 conductor circuit Class B ±0.3°C at 0°C according to DIN EN 60751 A - el=80mm, kl=1060mm B - EL=26mm, kl=1280mm Harting HAN HPR 3 with HAN Q5 (RoHS Compliant) Cable: Shielded Hose Line 2x [4xAWG 24/7 Cu-Silver-Plated/STP/Polyester Film/Cu-tinned/STPAØ: 4.2mm] BK (RD/RD/WH/WH) Plastic corrugated pipe hose Aø=10mm VCST-07B, Measuring range ፦40°C... +125°C Ambient temperature ፦40°C... +125°C Insulation resistance: ≥ 200 MΩ/500 VDC Shielding use on the sensor side: screen not attached to the sensor housing Umbrella use on the connection side: screen mounted on the plug housing 2 x 2-wire circuit merged on Harting plug 5-pin with 4 pin contacts, without pipe clamps and screws, only with sensor head screws AL: N/ECCN: N

Ephy Mess - 995150302000001 referenced Harness, AVE transmission/Gearbox product produced by high technology.
995150302000001 became irreplaceable of foundations. 995150302000001 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. 995150302000001 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy 995150302000001 by Ephy Mess in Germany?

You can purchase 995150302000001 by Ephy Mess from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.

What is the price of the 995150302000001?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Ephy Mess in Germany?

While we are not the official distributor or seller of Ephy Mess in Germany, we source our products from reliable channels and offer you original Ephy Mess equipment at competitive prices.

How can I access 995150302000001 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 995150302000001 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 995150302000001?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
