| BRAND | Labom |
| Product | CC6020-B1111-H2-T310 DL2100-HY-A4007-L22 |
| Internal code | IMP4960687 |
| Weight | 1.6 |
| Custom code | 90262020 |
| Technical specification | CC6 PRESSURE TRANSMITTER COMPACT for diaphragm seal operation 02 design: with temperature decoupler see data sheet D4-020-7 0 explosion protection: without B1 pressure sensor piezoresistive for absolute pressure 111 measuring range 1...11 bar abs., overload limit 60 bar measuring accuracy: linearity error incl. hysteresis < + 0.2 % f.s. accuracy of adjustment < +/- 0.2 % f.s. H2 output signal: 0...20 mA, 3-wire technology T31 electrical connection: cable connection IP 67, union nut of polyamide 0 2 m cable length DL DIAPHRAGM SEAL for food / pharmaceutical / biotechnology 2 design with coupling nut -see data sheet D5-025 100 process connection: DIN 11851, DN 25 / PN 40 HY hygienic design per EHEDG Doc.8 and ASME BPE SF3 surface roughness (wetted parts) - turned parts Ra <= 0.76 μm - diaphragm Ra <= 0.38 μm - weld seam Ra <= 0.76 μm A400 connection of meas. instrument directly welded 7 material wetted parts: stainless steel mat.-no. 1.4435 (316L) L22 system filling: Synthetic oil, free of silicon FD1 acc. to FDA 21 CFR 178.3570 / H1-registered design temperature process -10...+140 °C |
Where can I buy CC6020-B1111-H2-T310 DL2100-HY-A4007-L22 by Labom in Germany?
You can purchase CC6020-B1111-H2-T310 DL2100-HY-A4007-L22 by Labom from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the CC6020-B1111-H2-T310 DL2100-HY-A4007-L22?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Labom in Germany?
While we are not the official distributor or seller of Labom in Germany, we source our products from reliable channels and offer you original Labom equipment at competitive prices.
How can I access CC6020-B1111-H2-T310 DL2100-HY-A4007-L22 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CC6020-B1111-H2-T310 DL2100-HY-A4007-L22 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CC6020-B1111-H2-T310 DL2100-HY-A4007-L22?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
