| BRAND | BFI AUTOMATION |
| Product | CFC2000IR1 / 6013-2071-00 |
| Description | Compact Flame Controller |
| Internal code | IMP4672683 |
| Weight | 1.5 |
| Custom code | 84169000 |
| Technical specification | 6013-2071-00 Replaces part no.: 5 520.7 Compact Flame Controller CFC2000IR1 Relay and 0/4-20 mA output Dual channel compact system for continuous monitoring of Sulphur Recovery Units and gas burners of any power with additional frequency analysis for a better selectivity. The compact flame controller is equipped with a semiconductor sensor whose spectral sensitivity lies in the IR range. An electronic self-monitoring ensures safe operation. Flame intensity as well as the flame relay status is indicated via LEDs, Safety switch-off time can be predefined via Jumper and set by software (1-55). Sensitivity, switch-ON/OFF level and switch ON delay are controlled by software. Online frequency analysing and visualisa- tion of flame radlation is possible with the BFI software. Technical details: sensitivity levels: 2, separate and adjustable Flame relay: potential-free change-over contact max. 48V switching voltage max. 1A switching current max. 30W switching power Flame signal output: 0/4-20mA (Ra < 250 Ohm) Supply voltage: 24V DC Current consumption: approx. 200mA Spectral range: 1050-2700nm Viewing angle: 2.7° Self checking: once per 800ms Ambient temperature: -20 to +70°C Data transfer: RS232/Infrared Interface Electrical connection: Harting-plug 90° Dimension [mm]; L235 x W 108 x H 190 Housing: aluminum, RAL5010, IP65 ATEX-Zone2: II 3G Ex ec nC II T4GC SIL: SıL3 |
Where can I buy CFC2000IR1 / 6013-2071-00 by BFI AUTOMATION in Germany?
You can purchase CFC2000IR1 / 6013-2071-00 by BFI AUTOMATION from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the CFC2000IR1 / 6013-2071-00?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of BFI AUTOMATION in Germany?
While we are not the official distributor or seller of BFI AUTOMATION in Germany, we source our products from reliable channels and offer you original BFI AUTOMATION equipment at competitive prices.
How can I access CFC2000IR1 / 6013-2071-00 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CFC2000IR1 / 6013-2071-00 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CFC2000IR1 / 6013-2071-00?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
