Prices CFSI 100 KG IP68 Ascell Sensor Germany

BRAND	Ascell Sensor
Product	CFSI 100 KG IP68
Description	Loadcell
Internal code	IMP1782404
Weight	0.8
Technical specification	Ref. 104101 Divisions nLC 3000 Minimum Dead load Emin 0 kg Z= Emax / 2DR 3000 Y= E max./ Vmin. 10000 Rated Capacity Emax 50 - 75 - 100 - 150 - 300 - 500 kg Rated Sensitivity C 2 ± 0,1 % mV/V Rated Input Voltage 10 V dc Input Voltage Range 5...15 V ac/dc Input Resistance RLC 350 ± 3 Ω Output Resistance 350 ± 3 Ω Zero Balance ± 2 % Emax Insulation Resistance at 50 V DC > 5000 MΩ Service Overload > 150 % Emax Overload Limit > 300 % Emax Temperature Range : Compensated - 10 ... 40 ºC Operating - 30 ... 85 ºC Storage - 30 ... 90 ºC Max. Nonlinearity 0,02 % Emax Max. Hysteresis 0,02 % Emax Max. No repeatability 0,01 % Emax M Max. Creep in 4 hours 0,03 % Emax Max. Zero Recovery Test in ½ hour 0,011 % Emax Max Temperature effect : On Sensitivity 0,0013 % Emax / ºC On Zero 0,0014 % Emax / ºC Weight 800 g Cable Length 5 m Environmental Protection IP68 - DIN 40050 (100h 1m)

You can find the current prices belongs to Ascell Sensor - CFSI 100 KG IP68 coded Loadcell product. You can ask all the codes and references except CFSI 100 KG IP68 too. Our company supply CFSI 100 KG IP68 referenced product fastest and securest on your request. You can find the most competitive prices about endustriel accessories in our company. Make an offer to us for CFSI 100 KG IP68 please contact us.
