| BRAND | Tri-Tronics |
| Product | CMS-1BF1 |
| Description | Sensor |
| Internal code | IMP1879418 |
| Weight | 1 |
| Technical specification | COLORMARK™ II, 10ms Pulse Stretcher, Green LED, F1 Optical Block. 12-24 VDC polarity protected. Fiberoptic. Maximum Sensing Range is depending on fiber optics. Supply Voltage:12 to 24 VDC, Polarity Protected Current Requirements:85mA (exclusive of load) Output Transistors: (1) NPN and (1) PNP output transistor NPN: Sink up to 150mA PNP: Source up to 150mA Momentary short circuit protected Output transistors turn “ON” when mark is in view Anti-pulsing on power-up Response Time- Minimum duration of input event Light state response: 50 microseconds Dark state response: 140 microseconds Leading edge variation: less than 20 microseconds Hysteresis: Less than 400 millivolts for maximum sensitivity and resolution OFFSET/EDR® Clutch Knob Adjustment - Sets initial level on Contrast Indicator in relation to mid-scale switch point of 5 – functions as sensitivity adjustment. Controls Enhanced Dynamic Range circuit (EDR®) which functions to avoid glare effect LIGHT/DARK Switch: Dark position for dark mark; Light position for light mark Indicators: OUTPUT INDICATOR - Red LED illuminates when output transistors are “ON” EDR INDICATOR – Intensity of Green LED provides indication of where in the dynamic operating range the offset / EDR adjustment has been set FULLY LIT: Operating near saturation OFF: Operating near maximum sensing range CONTRAST INDICATOR –Displays returned contrasting light levels (background vs. mark) Light Immunity: Pulse modulated to provide extremely high immunity to ambient light Ambient Temperature: -40°C to 70°C (-40°F to158°F) Rugged Construction: Chemical resistant, high-impact polycarbonate housing Waterproof, ratings: NEMA 4X, 6P and IP67 Epoxy encapsulated for mechanical strength |
Where can I buy CMS-1BF1 by Tri-Tronics in Germany?
You can purchase CMS-1BF1 by Tri-Tronics from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the CMS-1BF1?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Tri-Tronics in Germany?
While we are not the official distributor or seller of Tri-Tronics in Germany, we source our products from reliable channels and offer you original Tri-Tronics equipment at competitive prices.
How can I access CMS-1BF1 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CMS-1BF1 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CMS-1BF1?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
