Prices  A-CONDUTEC-K-PZM-0000-  Hengesbach  Germany

BRAND Hengesbach
Product A-CONDUTEC-K-PZM-0000-
Description Conductivity transmitter
Internal code IMP4610676
Weight 1.2
Custom code 90278930
Technical specification Conductive Conductivity Meter CONDUTEC_K_PZM_0000 Compact design (transmitter and conductivity measuring cell fixed connected). Process connection: modular system PZM with pressure screw, material tool 1.4404 1. transmitter: Polyamide housing, dimension 100x100x60mm³, with integrated digital display. Measurement ranges freely programmable from 0.. 20 μS/cm to max. 0.. 500 mS/cm (see relevant technical data of the LF measuring cell) 1st output 4-20 mA, 2-wire for conductivity, galvanically isolated 2nd output 4-20 mA in 2-wire for temperature, programmable in the range T=- 40.. +160°C 2 contactless alarm outputs supply voltage 14... 30 VDC 2. 4-electrode conductivity measuring cell Can be used for conductivities in the range 0... 1 mS/cm to 0... 500 mS/cm. Accuracy approx. 0.02 mS/cm. Cell constant C=0.4 (C=0.5 for process connection G1 and G3) Working temperature TA = -10... +120°C. Steam sterilizable for 1 h up to TR = 140°C. Compressive strength 16 max. bar Temperature measurement with integrated Pt1000 according to DIN IEC 751. Parts in contact with media made of PEEK, PVDF, graphite and stainless steel (tool 1.4404). According to data sheet A-CONDUTEC... in the currently valid version.

You can find the current prices belongs to Hengesbach - A-CONDUTEC-K-PZM-0000- coded Conductivity transmitter product. You can ask all the codes and references except A-CONDUTEC-K-PZM-0000- too. Our company supply A-CONDUTEC-K-PZM-0000- referenced product fastest and securest on your request. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for A-CONDUTEC-K-PZM-0000- Hengesbach . We present you the most competative price and delivery time on A-CONDUTEC-K-PZM-0000- referenced product.

Where can I buy A-CONDUTEC-K-PZM-0000- by Hengesbach in Germany?

You can purchase A-CONDUTEC-K-PZM-0000- by Hengesbach from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.

What is the price of the A-CONDUTEC-K-PZM-0000-?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Hengesbach in Germany?

While we are not the official distributor or seller of Hengesbach in Germany, we source our products from reliable channels and offer you original Hengesbach equipment at competitive prices.

How can I access A-CONDUTEC-K-PZM-0000- catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for A-CONDUTEC-K-PZM-0000- on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for A-CONDUTEC-K-PZM-0000-?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
