Prices EL 100, F05/F07 with square 17mm Elomatic Germany

BRAND	Elomatic
Product	EL 100, F05/F07 with square 17mm
Description	Electric quarter turn Actuator
Internal code	IMP558418
Weight	1
Technical specification	Specification Nominal Rotation: 90° Enclosure: IP65 ( Optional IP67 ) Temperature: -20°C to +70°C Electrical Entry: 3 x M20x 1,5 (others optional) Electrical Connection: By 12 and/or 16 point terminal Limit Switches: 4 x SPDT V3Micro Switches Torque Control: 2 x SPDT V3Micro Switches Duty Cycle: 30% Stall Protection: By thermostat in motor windings Heater: 10 Watt Supply Voltage: AC -220-240V 50 Hz Visual Indication: by raised dome on top cover Finish: polyurethane paint (Yellow) External Steel Parts: Stainless Steel Datasheet: 5.103.3 (Minimum customer switch or contactor rating 16 Amp.)

Elomatic - EL 100, F05/F07 with square 17mm referenced Electric quarter turn Actuator product produced by high technology.
EL 100, F05/F07 with square 17mm became irreplaceable of foundations. EL 100, F05/F07 with square 17mm referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
