Prices  P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC  AC Motoren  Germany

BRAND AC Motoren
Product P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC
Description rotor cage asynchronous motor
Internal code IMP4475348
Weight 60
Custom code 85015230
Technical specification Motor power: 7.50 KW Number of motor poles: 4 Motor voltage: 3 x 400/ 690 V +- 10%, 50 Hz 3 x 460/ 725 V+- 10%, 60 Hz Engine speed: 1460 rpm Rated motor current: 14.25 /8.4 A Efficiency class: IE3 Efficiency: 90.4 - 90.4 - 88.6% at 4/4 - ¾/2/4 load cos phi: 0.84 Degree of protection: IP 55 Insulation class: F Design: IM B5 flange version Motor flange: IEC 132 B5 (drm.300 mm) Motor shaft: 38 k6 x 80 mm Weight: approx. 60 kg Terminal box location: top Coolant temperature: -20 to +40 °C Installation height: < 1000 m and sea level Coloring: RAL 7030 stone grey

AC Motoren - P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC referenced rotor cage asynchronous motor product produced by high technology.
P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC became irreplaceable of foundations. P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC by AC Motoren in Germany?

You can purchase P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC by AC Motoren from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.

What is the price of the P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of AC Motoren in Germany?

While we are not the official distributor or seller of AC Motoren in Germany, we source our products from reliable channels and offer you original AC Motoren equipment at competitive prices.

How can I access P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for P/N : 103973 , Type : FCA 132 M-4 / PHE B5 - PTC?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
