Prices FP 3402/110 KF Fristam Germany

BRAND	Fristam
Product	FP 3402/110 KF
Description	Centrifugal pump
Internal code	IMP4487693
Custom code	84137051
Technical specification	Part 0406000001 Pump on KF bearing carrier Pump material: 1.4404 (316L) Shaft seal: 9.665 (2N5P2/2N5P2) 1. coal/cast chrome/NBR 2. coal/cast chrome/NBR Elastomers: NBR with FDA certification Connection type: DIN 2633 Suction side: DN 50 Pressure side: DN 40 Impeller diameter: 110 mm Engine: 0.75 kW, n = 2900 rpm 50 Hz, isoclass ISO: F Voltage: 230/400 V. IP 55 Funding data: Viscosity = 1 mPa*s — density = 1 kg/l Certificates/exams: - FDA certificate/ EC 1935/2004 engine: - Engine size IEC80 - Terminal box at the top - according to efficiency class IE3 Pumphead: - Connections: flange DIN 2633 Shaft seal: - Mechanical seal: double acting Sealing water pressure max. 0.2 bar incl. water connection with pipe G1/8" other agreements: Height to shaft centre: 180 mm Pump as S/no.: 0406 73 0082

Fristam - FP 3402/110 KF referenced Centrifugal pump product produced by high technology.
You can ask all the codes and references except FP 3402/110 KF too. FP 3402/110 KF referenced product which is satisfy the customer's needs, offers advantages of quality and cost. You can find the most competitive prices about endustriel accessories in our company. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
