| BRAND | Labom |
| Product | PASCAL CV4110 |
| Description | Pressure Transmitter |
| Internal code | IMP4505168 |
| Weight | 2 |
| Custom code | 90262020 |
| Technical specification | CV4110 PRESSURE TRANSMITTER PASCAL CV4 for diaphragm seal operation see data sheet D4-016-7 R70 positioning process connection at back A1059 nominal range: 0...16 bar, Turndown max. 20:1, overload limit 60 bar; sensor type piezoresistiv F9 parameterizing: see below lower range value: - 1,0000 upper range value: + 5,0000 unit: bar Q2 accuracy: <= 0.15% from adjusted measuring span (Lin./Hys./Rep., up to Turndown <= 5:1 no changes) H21 output signal: 4...20 mA with HART protocol (Universal Commands) M21.1 high-resolution graphic display with backlight intuitive 4-button operation, quick access to device data available languages (English, German, Chinese), default setting English Y12 material case/window: stainless steel mat.-no. 1.4301/1.4305 (304/303), window non-splittering glass T1 degree of protection: IP 65 / IP 67 T30 electrical connection: circular connector M12 x 1 (4 pin) U1 temperature, ambient: -20...+80 °C W4020 marking: marking (adhesive label), see below W1201 INSPECTION CERTIFICATE DIN EN 10204 3.1 calibration certificate with 5 measuring points A420 connection of meas. instrument with temperature decoupler, directly welded L22 system filling: Synthetic oil, free of silicon FD1 acc. to FDA 21 CFR 178.3570 / H1-registered operating temperature range -10...+140 °C DF INLINE DIAPHRAGM SEAL for food / pharmaceuticals / biotechnology see data sheet D5-064 35 process connection: for pipes per DIN 11850 Tri-clamp connection on both sides 00 nominal width: pipe DN 15, pipe inside-ø 16 mm Tri-Clamp connection DN 3/4" / PN 25, outside-ø 25 mm HY hygienic design per EHEDG Doc.8 and ASME BPE SF3: surface roughness (wetted parts) - turned parts Ra <= 0.76 μm - diaphragm Ra <= 0.38 μm - weld seam Ra <= 0.76 μm F4 insertion length L: 96 mm G7 material wetted parts: diaphragm st. steel mat.-no. 1.4435 (316L), basic body st. steel mat.-no. 1.4404 (316L) W4035 ADDITIONAL DESIGN: wetted parts electropolished W1020 Components marked acc. to material inspection certificate per EN 10204-3.1, wetted parts W1223 INSPECTION CERTIFICATE DIN EN 10204 3.1 roughness height rating Ra |
Where can I buy PASCAL CV4110 by Labom in Germany?
You can purchase PASCAL CV4110 by Labom from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the PASCAL CV4110?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Labom in Germany?
While we are not the official distributor or seller of Labom in Germany, we source our products from reliable channels and offer you original Labom equipment at competitive prices.
How can I access PASCAL CV4110 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PASCAL CV4110 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PASCAL CV4110?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
