Prices VNT-XSF-1020-520-010 Brilex Germany

BRAND	Brilex
Product	VNT-XSF-1020-520-010
Description	Standard Explosion Vent Flat Rectangular
Internal code	IMP499352
Weight	1
Technical specification	Standard Explosion Vent Flat Rectangular Burst Pressure:0.10BarG +-25% @ 15-30 C To 1/3 SPECIFICATION Maximum Working Pressure:0.05BarG @ 15-30 C 1/3 SPECIFICATION Standard Explosion Vent Flat Rectangular Rectangular Explosion Vent External Size:1100 mm x 600 mm Internal Size: 1020 mm x 520 mm Vent Area: 0.52 Top Section Austenitic Stainless Steel Seal Membrane:Flouropolymer (Over 120C Aluminium) Bottom Section :Austentic Stainless Steel Burst Pressure:0.10 BarG +/ 25% Temperature Coefficient to drawing 00/00/08115 This explosion vent has a hole pattern designed to be installed into a frame supplied by Elfab.This assembly meets the requirements of directive 94/9/Ec(Atex) the user must coduct theus own risk assessment if they intend intend to use either a different hole pattern or a non Elfab supplied frame hole pattern to Elfab Standard

You can find the current prices belongs to Brilex - VNT-XSF-1020-520-010 coded Standard Explosion Vent Flat Rectangular product. You can ask all the codes and references except VNT-XSF-1020-520-010 too. All of the listed products are with guaranteed origin and high quality. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
