Prices PN: ZM18RF027 / Z5M18B-F-635-lg90 Z-LASER Germany

BRAND	Z-LASER
Product	PN: ZM18RF027 / Z5M18B-F-635-lg90
Description	positioning laser
Internal code	IMP1702556
Weight	0.2
Custom code	9013 2000
Technical specification	Z-LASER Model Z5M18b-F-635-LG90 SYSTEM SPECIFICATIONS: Wavelength (typ.) 635nm Output power (typ.) 5mW Boresight Error (Typ.) <10mrad Pointing Stability <15μrad/ °C ± 3% power stability over the entire temperature range APC operating mode Laser class (EN 60825-1) 1M ELECTRICAL SPECIFICATIONS: Supply voltage 5-30VDC Connection M12x1 circular connector, 4-pin OPTICAL SPECIFICATIONS: Standard line projection, 90° opening angle LG90 optics Focus can be focused Focusing range can be focused from 100mm to 10,000mm DIGITAL MODULATION: - ANALOG MODULATION: - AMBIENT CONDITIONS: Operating temperature -10°C to +50°C Storage temperature -40°C to +85°C Relative humidity (max) < 90%, non-condensing Heat loss (max.) <1W MECHANICAL SPECIFICATIONS: M18 industrial housing, chrome-plated brass diameter 20mm Length 108mm Protection class IP67 24-month warranty

You can find the current prices belongs to Z-LASER - PN: ZM18RF027 / Z5M18B-F-635-lg90 coded positioning laser product. You can ask all the codes and references except PN: ZM18RF027 / Z5M18B-F-635-lg90 too. We are one of the few companies which can present an offer for this product. You can find the most competitive prices about endustriel accessories in our company. Make an offer to us for PN: ZM18RF027 / Z5M18B-F-635-lg90 please contact us.
