Prices Z692690502 Rotork Germany

BRAND	Rotork
Product	Z692690502
Description	spare Actuator
Internal code	IMP3424325
Weight	54
Technical specification	IQM25 F14 A [IP68] 24RPM 380/3/50 Wiring diagram 203B0000 Wiring diagram 203B0000 is described in IQ/IQT Control and Monitoring publication (PUB002-041) and includes: • CONTROL SUPPLY: 20 – 60VDC/40 – 120VAC or actuator derived 24VDC • CONTROL INPUTS: 6 inputs for open, close, stop/maintain, ESD and interlock signals, 20 – 60VDC/40 – 120VAC • INDICATION CONTACTS: 4 volt-free (SPST) latching contacts (S1-S4), rated at 120VAC/30VDC, 5mA to 5A, each configurable NO or NC to signal one of the following; open/closed or intermediate positions, moving (continuous or pulsing), Handwheel operation, local selected, remote selected, open/close interlock active, ESD active, motor tripped on torque in mid travel/going open/going closed, valve jammed, loss of power/phase or control supply, battery low, internal failure detected, thermostat tripped, programmable service alarms. • MONITOR AND AVAILABILITY RELAY: Independent relay with volt-free changeover contact, rated at 120VAC/30VDC, 5mA to 5A. De-energises in case of; loss of power/phase or control supply, local control or local stop selected (can be excluded), motor thermostat tripped or detected internal failure • ANALOGUE CONTROL/FEEDBACK: Proportional control over whole or part of valve stroke 0 to 5/10/20/mA or volt ranges, internally powered 4-20mA output proportional to position (Folomatic/CPT). Configurable for open, close or stay-put on loss of signal. Incorporates user adjustable deadband (percentage of signal) and motion inhibit time (seconds) for restricting hunting or over modulation caused by a fluctuating control signal.

Rotork - Z692690502 referenced spare Actuator product produced by high technology.
Z692690502 became irreplaceable of foundations. Z692690502 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Our company can make an offer even if we do not distributor of Germany. Contact us if you are looking for alternative price of Z692690502 .

Where can I buy Z692690502 by Rotork in Germany?

You can purchase Z692690502 by Rotork from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.

What is the price of the Z692690502?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Rotork in Germany?

While we are not the official distributor or seller of Rotork in Germany, we source our products from reliable channels and offer you original Rotork equipment at competitive prices.

How can I access Z692690502 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Z692690502 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for Z692690502?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
