Prices Z80-X20-H-F-660-SLP60 Z-LASER Germany

BRAND	Z-LASER
Product	Z80-X20-H-F-660-SLP60
Internal code	IMP4938064
Technical specification	722135016 Z-LASER Z80-x20-H-F-660-SLP60 SYSTEM SPECIFICATIONS: Wavelength (typ.) 660nm wavelength tolerance ±10nm Wavelength drift (typ.) 0.25nm/K Output power (typ.) 80mW Transverse Mode Single Transverse Mode RMS noise (20 Hz to 20 MHz, typical) < 0.5% peak-to-peak noise (20 Hz to 20 MHz, type.) < 1% Boresight Error (typ.) typ. 3mrad Pointing Stability <10μrad/ K ± 3% power stability over the entire temperature range Start time <2sec APC operating mode Laser class (EN 60825-1) 3R ELECTRICAL SPECIFICATIONS: Supply voltage 5-30VDC Operating current (max) <500mA Electrical insulation Potential-free housing M12 5-pin connector: A-pining connector Power consumption <2.5W I²C, RS-232 (5V) interfaces OPTICAL SPECIFICATIONS: projection line, homogeneous intensity distribution Standard line optical configuration (slp) Opening angle 60° Line straightness < 0.05% Line orientation parallel to the groove in the clamping area Focusing range can be focused from 100mm to 10,000mm Maximum frequency up to 400kHz Rise time <100ns Fall time <100ns signal level < +0,9V (VIL_max) & > +2.2 V (vIH_min) Operating range (VDC) 0-30VDC Maximum bandwidth <10Hz Linearity < 5% (from 10% to 100% of laser power) 0-2VDC active range Impedance 100 kΩ to internal VCC (3.3 V) Max. voltage range 0-30VDC AMBIENT CONDITIONS: Operating temperature -10°C to +50°C/14°F to +122°F Storage temperature -40°C to +85°C/-40°F to +185°F Relative humidity (max) < 90%, non-condensing Heat loss (max.) <1W Shock and vibration in accordance with IEC EN 61373:2011, Cat. 2 MECHANICAL SPECIFICATIONS: Net weight 125g/0.28 lbs Case dimensions (ø x L) 20h7 x 117mm/0.79 x 4.61 in Material stainless steel Protection class IP67 24-month warranty

You can find the current prices belongs to Z-LASER - Z80-X20-H-F-660-SLP60 coded product. You can ask all the codes and references except Z80-X20-H-F-660-SLP60 too. It distinguishes with price and quality among the similar products. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for Z80-X20-H-F-660-SLP60 Z-LASER . Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
