| BRAND | Labom |
| Product | CC6020-A1093-H1-T110-W4999 |
| Internal code | IMP4982788 |
| Weight | 1 |
| Custom code | 90262020 |
| Technical specification | DE1180-D4-A4001-L23-T99-W4999 Order Code: PRESSURE TRANSMITTER COMPACT for diaphragm seal operationCC6 design: with temperature decoupler see data sheet D4-020-7 02 explosion protection: without0 pressure sensor piezoresistive for gauge pressureA1 measuring range -1...24 bar, overload limit 60 bar measuring accuracy: linearity error incl. hysteresis < + 0.2 % f.s. accuracy of adjustment < +/- 0.2 % f.s. 093 output signal: 4...20 mA, 2-wire technologyH1 electrical connection: right angle plug acc. to DIN EN 175301-803-A (DIN 43650, model A) IP 65, for cable ø 4...10 mm T110 ADDITIONAL DESIGN: see belowW4999 design for process temperature up to 205°C DIAPHRAGM SEAL for general application, screw-in thread see data sheet D5-032 process connection: G1/2 A per DIN 3852 model A118 design: standard0 nominal pessure: PN 400D4 connection of meas. instrument directly weldedA400 material wetted parts: stainless steel mat.-no. 1.4404/1.4435 (316L)1 system filling: Synthetic oil, free of silicon FD1 acc. to FDA 21 CFR 178.3570 / H1-registered L23 temperature range: see belowT99 -20......+205°C ADDITIONAL DESIGN: see belowW4999 suitable for clamping sleeves like F1-AC-00334-k # Spare part for Fab.-No.: 2313007/10/001 |
Where can I buy CC6020-A1093-H1-T110-W4999 by Labom in Germany?
You can purchase CC6020-A1093-H1-T110-W4999 by Labom from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the CC6020-A1093-H1-T110-W4999?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Labom in Germany?
While we are not the official distributor or seller of Labom in Germany, we source our products from reliable channels and offer you original Labom equipment at competitive prices.
How can I access CC6020-A1093-H1-T110-W4999 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CC6020-A1093-H1-T110-W4999 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CC6020-A1093-H1-T110-W4999?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
