| BRAND | Labom |
| Product | CV3101-A1053-F80-H1100-M2-N10-T20-K1010-S66-W4020 |
| Description | pressure transmitter |
| Internal code | IMP3902644 |
| Weight | 0.65 |
| Custom code | 90262020 |
| Technical specification | PRESSURE TRANSMITTER PASCAL CV with threaded connection according to data sheet D4-017-1 CV310 1 Explosion protection: with explosion protection A1 pressure sensor: piezoresistive for overpressure 053 Nominal range: 0... 1 bar, overload limit 3 bar Measuring range setting: 5:1 turndown Accuracy: <= 0.15% of the set measuring range (Lin. /Hys. /Rep.) F80 measuring range: set see below Initial value: - 1,000 Full scale: + 0.600 Unit: bar H11 output signal: 4... 20 mA, characteristic curve rising 0 Attenuation: 0.0 sec standard 0 Setting-alarm state: < 3.6 mA, default M2display module: multi-function display with 5-digit digital display and bar graph, pluggable N10 switching module: without Housing: hygienic housing design with screw cap Material: stainless steel Chassis protection class: IP 66 K1010 process connection: internal membrane, G 1/2 B according to DIN EN 837-1 Material: - Diaphragm stainless steel W. no. 1.4404/1.4435 (316L) - Stub stainless steel W. no. 1.4404/1.4435 (316L) S66 Ex version: TUV 04 ATEX 2387 X II 1/2 G Ex ia IIC T4/T5/T6 Ga/Gb Please note the operating conditions that can be found in the data sheet and the Ex-Safety Note XA_015 and XA_020! with current output (XA_015) with PROFIBUS PA (XA_020) W4020 ADDITIONAL TYPE: Identification (label), see below T20 electrical connection: cable gland M16x1.5 PA black |
Where can I buy CV3101-A1053-F80-H1100-M2-N10-T20-K1010-S66-W4020 by Labom in Germany?
You can purchase CV3101-A1053-F80-H1100-M2-N10-T20-K1010-S66-W4020 by Labom from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the CV3101-A1053-F80-H1100-M2-N10-T20-K1010-S66-W4020?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Labom in Germany?
While we are not the official distributor or seller of Labom in Germany, we source our products from reliable channels and offer you original Labom equipment at competitive prices.
How can I access CV3101-A1053-F80-H1100-M2-N10-T20-K1010-S66-W4020 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CV3101-A1053-F80-H1100-M2-N10-T20-K1010-S66-W4020 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CV3101-A1053-F80-H1100-M2-N10-T20-K1010-S66-W4020?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
