Prices GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1 Labom Germany

BRAND	Labom
Product	GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1
Description	Rezistans Termomether
Internal code	IMP4013845
Weight	2
Custom code	90251900
Technical specification	RESISTANCE THERMOMETER MiniTherm for food/pharmaceuticals/biotechnology acc. to data sheet T4-015 measuring resistor: Pt 100, tolerances per class A per DIN EN 60751 GA2700-HY A10 process connection: threaded connection 31 nominal width: M12x1.5, conical seal C4 temperature detecting element: ø 6 mm, reduced design to ø 4 mm 025 insertion length U1: 25 mm G11 material wetted parts: stainless steel mat.-no. 1.4404 (316L) N2 measuring resistor: 1 x Pt100, 3-wire technology, standard T150 electrical connection: circular connector M12 x 1 (4 pins) incl. transmitter into st. steel plug housing with locking plug M12 (type PA2430) Z52 TRANSMITTER for temperature (Pt 100), programmable see data-sheet T4-082-1 with circular connector M12x1 (4-pins) PA243 0 design: standard F12 configuration: see below measuring range: 0...+150 °C error current if there is a sensor break 22.8 mA sensor offset: 0 °C, standard damping: 0 s, standard

You can find the current prices belongs to Labom - GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1 coded Rezistans Termomether product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. All of the listed products are with guaranteed origin and high quality. You can find the most competitive prices about endustriel accessories in our company. Contact us if you are looking for alternative price of GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1 .

Where can I buy GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1 by Labom in Germany?

You can purchase GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1 by Labom from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.

What is the price of the GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Labom in Germany?

While we are not the official distributor or seller of Labom in Germany, we source our products from reliable channels and offer you original Labom equipment at competitive prices.

How can I access GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for GA2700-HY-A1031-C4025-G11-N2-T150-Z52 PA2430-F12-H1?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
